| Picture | ES Part No. | Part No | Stock | Price | Datasheet | Pb Free | RoHS | Description | Vendor | Capacitance | Tolerance | Voltage-Rated | Endurance (Hours) | Series | Lead Spacing | Diameter x Height(mm) |
| | | | | | | | | | | | | | | | |
 | 0289-0147-7 | UWX1H3R3MCL1GB | 1,664 | 1.14 |  | PB-Free | | E-Cap WX Series 3.3μF/50Volt -40°C to +85°C,±20%,2000hrs. Chip Type with 5.5mm Height | NICHICON | 3.3μF | ±20% | 50V | 2000 | WX,Chip type with 5.5mm height 85°C,2000hrs | 1.0mm | 4x5.5 |
 | 0289-0148-0 | UWX1H4R7MCL1GB | 4,788 | 2.21 | | PB-Free | RoHS | E-Cap WX Series 4.7μF/50Volt -40°C to +85°C,±20%,2000hrs. Chip Type with 5.5mm Height | NICHICON | 4.7μF | ±20% | 50V | 2000 | WX,Chip type with 5.5mm height 85°C,2000hrs | 1.3mm | 5x5.5 |
 | 0289-0149-3 | UWX1H100MCL1GB | 7,295 | 3.11 | | PB-Free | | E-Cap WX Series 10μF/50Volt -40°C to +85°C,±20%,2000hrs. Chip Type with 5.5mm Height | NICHICON | 10μF | ±20% | 50V | 2000 | WX,Chip type with 5.5mm height 85°C,2000hrs | 2.2mm | 6.3x5.5 |
 | 0289-0150-0 | UWX1H220MCL1GB | 801 | 3.12 | | PB-Free | | E-Cap WX Series 22μF/50Volt -40°C to +85°C,±20%,2000hrs. Chip Type with 5.5mm Height | NICHICON | 22μF | ±20% | 50V | 2000 | WX,Chip type with 5.5mm height 85°C,2000hrs | 2.3mm | 8x5.5 |
| 0289-0151-3 | UWX1H330MCL1GB | 692 | 5.18 | | PB-Free | | E-Cap WX Series 33μF/50Volt -40°C to +85°C,±20%,2000hrs. Chip Type with 5.5mm Height | NICHICON | 33μF | ±20% | 50V | 2000 | WX,Chip type with 5.5mm height 85°C,2000hrs | 2.3mm | 8x5.5 |
 | 0289-0153-9 | UWT0J330MCL1GB | 5 | 1.76 | | PB-Free | | E-Cap WT Series 33μF/6.3Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 33μF | ±20% | 6.3V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 1.3mm | 5x5.4 |
 | 0289-0155-5 | UWT0J101MCL1GB | 593 | 3.13 | | PB-Free | | E-Cap WT Series 100μF/6.3Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 100μF | ±20% | 6.3V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 2.2mm | 6.3x5.4 |
 | 0289-0156-8 | UWT0J221MCL1GB | 1,025 | 6.07 | | PB-Free | | E-Cap WT Series 220μF/6.3Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 220μF | ±20% | 6.3V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 2.3mm | 8x5.4 |
 | 0289-0157-1 | UWT0J331MCL1GS | 1,643 | 3.34 | | PB-Free | | E-Cap WT Series 330μF/6.3Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 330μF | ±20% | 6.3V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 2.2mm | 6.3x7.7 |
 | 0289-0158-4 | UWT0J102MNL1GS | 5,168 | 7.91 | | PB-Free | | E-Cap WT Series 1000μF/6.3Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 1000μF | ±20% | 6.3V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 3.1mm | 8x10 |
| 0289-0159-7 | UWT1A220MCL1GB | 7,378 | 2.69 | | PB-Free | | E-Cap WT Series 22μF/10Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 22μF | ±20% | 10V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 1.3mm | 5x5.4 |
| 0289-0160-4 | UWT1A330MCL1GB | 4,044 | 5.54 | | PB-Free | | E-Cap WT Series 33μF/10Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 33μF | ±20% | 10V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 1.3mm | 5x5.4 |
| 0289-0161-7 | UWT1A470MCL1GB | 19,549 | 3.14 | | PB-Free | | E-Cap WT Series 47μF/10Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 47μF | ±20% | 10V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 2.2mm | 6.3x5.4 |
| 0289-0162-0 | UWT1A101MCL1GB | 62 | 3.21 | | PB-Free | RoHS | E-Cap WT Series 100μF/10Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 100μF | ±20% | 10V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 2.2mm | 6.3x5.4 |
| 0289-0163-3 | UWT1A221MCL1GS | 338 | 3.54 | | PB-Free | | E-Cap WT Series 220μF/10Volt -55°C to +105°C,±20%,1000hrs. Chip Type | NICHICON | 220μF | ±20% | 10V | 1000 | WT,Chip Type/Wide Temperature range 105°C,1000hrs | 2.2mm | 6.3x7.7 |
