| Picture | ES Part No. | Part No | Stock | Price | Datasheet | Pb Free | RoHS | Description | Vendor | Case Style | Number of Rectifiers | Average Rectified Current | Reverse Voltage Max. | Reverse Recovery Time (trr) Typ. | Forward Voltage(Vf) @ If | Power | Package / Case | Mounting Type | Packaging | Technology | Mfr Package |
| | | | | | | | | | | | | | | | | | | | | |
 | 0176-0228-9 | RB056L-40TE25 | 19,162 | 4.83 |  | PB-Free | RoHS | Schottky Diode 40V/3A, General Purpose, Small Power Mold Type | ROHM | DO-214 | Single | 3A | 40V | - | 670mV @ 3A | - | DO-214AC (SMA) | Surface Mount | TAPE & REEL | Schottky Diode | PMDS |
| 0176-0235-4 | RB050L-60TE25 | 10,591 | 6.39 | | PB-Free | RoHS | Schottky Diode 60V/ 3A, General Purpose, Small Power Mold Type | ROHM | DO-214 | Single | 3A | 60V | - | 560mV @ 3A | - | DO-214AC (SMA) | Surface Mount | TAPE & REEL | Schottky Diode | PMDS |
 | 0176-0283-8 | RBQ20T45A | 1,708 | 15.30 | | PB-Free | RoHS | Schottky Barrier Diode 45V/20A Cathode Common Type | ROHM | TO-220 | Dual | 20A | 45V | - | 650mV @ 10A | - | TO-220F-3 | Through Hole | BAG | Schottky Diode | TO-220FN |
 | 0176-0300-2 | SCS210KE2C | 1 | 226.80 | | PB-Free | RoHS | Silicon Carbide Schottky Barrier Diode 1200V /10A 170W, High-speed switching possible Switching Time 15ns, Shorter recovery time | ROHM | TO-247,264,3P | Dual | 10A | 1200V | - | 1.6V @ 5A | 170W | TO-247-3 | Through Hole | TUBE | Silicon Carbide Schottky Diode | TO-247 |
| 0176-0302-8 | SCS230KE2C | 0 | 461.70 | | PB-Free | RoHS | Silicon Carbide Schottky Barrier Diode 1200V/30A 360W, High-speed Switching Possible Switching Time 18ns, Shorter Recovery Time | ROHM | TO-247,264,3P | Dual | 30A | 1200V | - | 1.6V @ 15A | 360W | TO-247-3 | Through Hole | TUBE | Silicon Carbide Schottky Diode | TO-247 |
| 0176-0303-1 | SCS240KE2C | 0 | 677.60 | | PB-Free | RoHS | Silicon Carbide Schottky Barrier Diode 1200V/40A 420W, High-speed switching possible Switching Time 18ns, Shorter recovery time | ROHM | TO-247,264,3P | Dual | 40A | 1200V | - | 1.4V @ 20A | 420W | TO-247-3 | Through Hole | TUBE | Silicon Carbide Schottky Diode | TO-247 |
 | 0176-0348-2 | SCS206AGC | 3 | 54.08 | | PB-Free | RoHS | Silicon Carbide Schottky Barrier Diode 650V/6A, Qc = 95nC High Speed Switching | ROHM | TO-220 | Single | 6A | 650V | - | 1.55V @ 6A | 51W | TO-220-2 | Through Hole | TUBE | Silicon Carbide Schottky Diode | TO-220AC |
| 0176-0349-5 | SCS208AGC | 63 | 64.97 | | PB-Free | RoHS | Silicon Carbide Schottky Barrier Diode 650V/8A, High Speed Switching | ROHM | TO-220 | Single | 8A | 650V | - | 1.55V @ 8A | 68W | TO-220-2 | Through Hole | TUBE | Silicon Carbide Schottky Diode | TO-220AC |
 | 0176-0351-5 | SCS210AMC | 0 | 103.60 | | PB-Free | RoHS | Silicon Carbide Schottky Barrier Diode 650V/10A, Qc = 15nC High Speed Switching | ROHM | TO-220 | Single | 10A | 650V | - | 1.55V @ 10A | 34W | TO-220F-2 | Through Hole | TUBE | Silicon Carbide Schottky Diode | TO-220FM |
| 0176-0355-7 | RB088T150 | 40 | 17.31 | | PB-Free | RoHS | Schottky Barrier Diodes 150V/10A, Cathode Common Dual Type | ROHM | TO-220 | Dual | 10A | 150V | - | 880mV @ 5A | - | TO-220F-3 | Through Hole | BULK | Schottky Diode | TO-220FN |
| 0176-0388-8 | RB068L100GTE25 | 0 | 5.15 | | PB-Free | RoHS | Schottky Barrier Diode 100V/2A, General Purpose Small Power Mold Type | ROHM | DO-214 | Single | 2A | 100V | - | 800mV @ 2A | - | DO-214AC (SMA) | Surface Mount | TAPE & REEL | Schottky Diode | PMDS |
| 0176-0495-8 | RB058L150TE25 | 7,343 | 5.40 | | PB-Free | RoHS | Schottky Barrier Diode 150V/3A Small power mold type | ROHM | DO-214 | Single | 3A | 150V | - | 850mV @ 3A | - | DO-214AC (SMA) | Surface Mount | TAPE & REEL | Schottky Diode | PMDS |
 | 0176-0509-9 | RB095BM-60TL | 9,229 | 11.47 | | PB-Free | RoHS | Schottky Barrier Diodes 60V/6A Cathode Common Dual Type Power Mold Type | ROHM | DPAK(TO-252),D2PAK(TO-263) | Dual | 6A | 60V | - | 580mV @ 3A | - | DPAK (TO-252) | Surface Mount | TAPE & REEL | Schottky Diode | TO-252 |
| 0176-0537-5 | RBQ10BM45ATL | 3,403 | 12.39 | | PB-Free | RoHS | Schottky Barrier Diode 45V/10A Cathode Common Type | ROHM | DPAK(TO-252),D2PAK(TO-263) | Dual | 10A | 45V | - | 650mV @ 5A | - | DPAK (TO-252) | Surface Mount | TAPE & REEL | Schottky Diode | TO-252 |
| 0176-0572-6 | RB095BM-90TL | 2,411 | 12.69 | | PB-Free | RoHS | Schottky Barrier Diodes 90V/6A Cathode Common Dual Type, Power Mold Type | ROHM | DPAK(TO-252),D2PAK(TO-263) | Dual | 6A | 90V | - | 750mV @ 3A | - | DPAK (TO-252) | Surface Mount | TAPE & REEL | Schottky Diode | TO-252 |
