| Picture | ES Part No. | Part No | Stock | Price | Datasheet | Pb Free | RoHS | Description | Package / Case | Power (Watts) | Resistance in Ohms | Tolerance | Series | Packaging | Vendor |
| | | | | | | | | | | | | | | |
 | 0842-0013-3 | KRL1220E-M-R068-F-T5 | 20 | 11.99 |  | PB-Free | RoHS | Metal Foil Current Sense Resistor 68mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 68mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0016-9 | KRL1220E-M-R005-F-T5 | 0 | 2.67 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 5mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 5mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0017-1 | KRL1220E-M-R006-F-T5 | 0 | 2.67 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 6mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 6mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0018-3 | KRL1220E-M-R007-F-T5 | 0 | 2.67 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 7mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 7mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0019-5 | KRL1220E-M-R010-F-T5 | 0 | 2.67 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 10mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 10mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0020-1 | KRL1220E-M-R012-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 12mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 12mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0021-2 | KRL1220E-M-R018-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 18mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 18mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0022-4 | KRL1220E-M-R022-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 22mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 22mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0023-6 | KRL1220E-M-R027-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 27mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 27mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0024-8 | KRL1220E-M-R033-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 33mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 33mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0025-1 | KRL1220E-M-R039-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 39mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 39mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0026-2 | KRL1220E-M-R047-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 47mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 47mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0027-4 | KRL1220E-M-R100-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 100mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 100mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0028-6 | KRL1220E-M-R120-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 120mΩ ±1% 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 120mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
| 0842-0029-8 | KRL1220E-M-R150-F-T5 | 0 | 0.00 | | PB-Free | RoHS | Metal Foil Current Sense Resistor 150mΩ ±1%, 1/2W, Wrap Around Terminal, Operating Temperature -55°C to 155°C, AEC-Q200 Compliant | 0805 (2012) | 1/2W | 150mΩ | ±1% | KRL-Current Sensing,Short-Side Terminal,Metal Foil | TAPE & REEL | SUSUMU |
